Merkmale D63H88
| Nominal data |
12V |
24V |
| Winding |
13.080 |
27.056 |
| No load speed (Rpm) |
3600 |
3500 |
| No load current (A) |
1,2 |
0,6 |
| Nominal speed (Rpm) |
3100 |
3000 |
| Nominal torque (Ncm) |
15 |
17 |
| Nominal current (A) |
5,5 |
2,8 |
| Nominal output power (W) |
50 |
52 |
| Efficiency (%) |
75 |
80 |
| Starting torque (Ncm) |
120 |
130 |
| Starting current (A) |
40 |
20 |
| Rotor moment inertia (gcm^2) |
350 |
350 |
| Weight (Kg) |
1 |
1 |
| Length L (mm) |
98 |
98 |
Merkmale D63H118
| Nominal data |
12V |
24V |
| Winding |
13.080 |
16.071 |
| No load speed (Rpm) |
2000 |
3300 |
| No load current (A) |
0,75 |
0,35 |
| Nominal speed (Rpm) |
1600 |
2800 |
| Nominal torque (Ncm) |
30 |
37 |
| Nominal current (A) |
6,4 |
5,9 |
| Nominal output power (W) |
80 |
160 |
| Efficiency (%) |
70 |
80 |
| Starting torque (Ncm) |
200 |
300 |
| Starting current (A) |
50 |
50 |
| Rotor moment inertia (gcm^2) |
550 |
550 |
| Weight (Kg) |
4 |
4 |
| Length L (mm) |
128 |
128 |
