Merkmale D35H49
| Nominal data |
12V |
24V |
| Winding |
51.0315 |
1000.0224 |
| No load speed (Rpm) |
5300 |
5350 |
| No load current (A) |
0,30 |
0,17 |
| Nominal speed (Rpm) |
4500 |
4550 |
| Nominal torque (Ncm) |
1,4 |
1,8 |
| Nominal current (A) |
1,2 |
0,7 |
| Nominal output power (W) |
7 |
8 |
| Efficiency (%) |
60 |
62 |
| Starting torque (Ncm) |
10 |
11 |
| Starting current (A) |
5,1 |
2,8 |
| Rotor moment inertia (gcm^2) |
35 |
35 |
| Weight (Kg) |
0,15 |
0,15 |
| Length L (mm) |
53 |
53 |
Merkmale D35H57
| Nominal data |
12V |
24V |
| Winding |
40.0355 |
60.028 |
| No load speed (Rpm) |
5000 |
5750 |
| No load current (A) |
0,29 |
0,15 |
| Nominal speed (Rpm) |
4250 |
4900 |
| Nominal torque (Ncm) |
2,3 |
2,7 |
| Nominal current (A) |
1,4 |
0,8 |
| Nominal output power(W) |
12 |
14 |
| Efficiency (%) |
64 |
66 |
| Starting torque (Ncm) |
15 |
18 |
| Starting current (A) |
8,5 |
4,8 |
| Rotor moment inertia (gcm^2) |
55 |
55 |
| Weight (Kg) |
0,2 |
0,2 |
| Length L (mm) |
61 |
61 |
